ASUS TUF GAMING B850-BTF WIFI DDR5 Motherboard - White

Key Features

• Ready for Advanced AI PC: Designed for the future of AI computing, with the power and connectivity needed for demanding AI applications
• AMD AM5 Socket: Ready for AMD Socket AM5 for AMD Ryzen 9000 & 8000 & 7000 Series Desktop Processors
• Hidden-Connector Design: Delivers an unprecedented lever of cable management to PC DIY enthusiasts
• Graphics Card High-Power Slot: Compatible with the PCIe high-power connector on the graphics card, delivering up to 600 watts through the motherboard
• Enhanced Power Solution: 14+2+1 80A DrMOS power stages, 8-layer PCB, 8+8 pin ProCool power connectors, alloy chokes and durable capacitors for stable power delivery
• Latest M.2 Support: One onboard PCIe 5.0 M.2 slot and two PCIe 4.0 M.2 slots, equipped with all M.2 heatsinks
• Ultrafast Connectivity: Wi-Fi 7, PCIe 5.0 x16 slot, Realtek 2.5Gb Ethernet, rear USB 20Gbps Type-C port, front USB 10Gbps Type-C connector, Thunderbolt (USB4) header support. Renowned Software: ASUS AI Advisor, TurboV Core, ASUS DriverHub, ASUS GlideX

Hidden-connector Design
The hidden-connector design can be ideal for first-time builders, because it provides easier cable management. The absence of visible cables also creates a clean and tidy look that would normally require an expert.

AI CACHE BOOST
Supercharge your large language model (LLM) workflows with AI Cache Boost. Exclusive to ASUS AMD 800 and 600 series motherboards that use Ryzen™ 9000 Series CPUs, this BIOS setting optimizes CPU cache and memory pathways to deliver up to 29% faster local LLM performance with high-speed memory tuning.

AI Advisor
ASUS AI Advisor is an ASUS technical expert that's always available to answer your questions. Owners of compatible ASUS motherboards can interact with this AI-powered technology using natural language to learn more about their hardware. For DIY beginners, it can provide easy-to-understand explanations of one-click optimization features like AI Overclocking and fan speed tuning, and for seasoned PC-building veterans, it can offer guidance and instructions on the latest features offered by ASUS.

UEFI BIOS
The UEFI interface delivers easy-to-use configuration options for PC beginners, and advanced features for veterans.

ASUS DriverHub
Simplify driver management with automatic detection, one-click installation and update for smooth, efficient system performance.

ASUS GlideX
Enable seamless screen sharing and control across PCs, tablets, and smartphones via USB or WiFi, supporting multiple platforms.

Armoury Crate
Customize Aura Sync RGB and control ASUS devices. Includes product registration and updates.

Premium Power Design
Stable power is crucial for maximizing the performance of AMD processors. The motherboard is designed to meet the needs of high-core-count CPUs. It features 14(80A) + 2(80A) + 1(80A) power stages that integrate high-side and low-side MOSFETs and drivers into packages rated for up to 80A each. This configuration ensures optimal power delivery, efficiency, stability and performance for both current and future AMD processors.

DRAM Overclocking Performance
Comprehensive memory tuning options are the cornerstone of TUF GAMING motherboards. With the motherboard, you can extract all the potential out of your DDR5 modules*, whether they're from an extreme-speed kit or an entry-level set that would otherwise be locked.

DDR5 DOMINANCE
For those who want to fly past stock DDR5 speeds, this motherboard is primed and ready for enthusiast-grade kits, courtesy of vast AMD Extended Profiles for Overclocking (EXPO™) support. Seasoned veterans can further tweak performance via an extensive array of settings in the UEFI.

ASUS AEMP
ASUS Enhanced Memory Profile (AEMP) is an exclusive firmware feature for PMIC-restricted memory modules. AEMP automatically detects the memory chips on your kit and then presents optimized frequency, timing and voltage profiles that you can quickly apply.

M.2 PCIe 5.0 Support
This motherboard also features one PCIe 5.0 M.2 slot to enjoy the fastest data transfers of up to 128 Gbps*, and all M.2 slots support NVMe RAID configurations to take advantage of the latest available speeds.

Empowering Connection
This motherboard offers a versatile range of connectivity with PCIe 5.0, rear USB 20Gbps Type-C® port, front USB 10Gbps Type-C® connector and Thunderbolt™ (USB4®) header support.

PCIe 5.0 for Graphics Card
PCIe 5.0 offers twice the data transfer speed of PCIe 4.0, making it robust enough to handle new data-heavy tasks. PCIe 5.0 also brings other benefits, such as electrical changes to improve signal integrity, backward-compatible CEM connectors for add-in cards and backward compatibility with previous versions of the PCIe bus.

Rear USB 20Gbps Type-C®
Extensive USB support ensures connections to a wide array of external devices. This motherboard includes a USB 20Gbps Type-C® port on the rear I/O panel that delivers transfer speeds of up to 20Gbps.

Front USB 10Gbps Type-C®
This motherboard features a USB 10Gbps Type-C® front panel connector for speedy data transfers of up to 10Gbps.

PCIe Slot Q-Release Slim
Simply tilt the card toward the latching mechanism to automatically unlock it from the PCIe slot. This makes upgrades and maintenance easier than ever before. Users will no longer need to fiddle with a tricky latch or even press a button to release their graphics card from the slot.

Ultrafast Networking
Provide a feature-packed high-performance gaming package, with ultrafast networking for smoother online gameplay.

Realtek 7.1 Channel Audio
ALC1220P
This motherboard utilizes an audio codec designed in close collaboration with Realtek — the Realtek ALC1220P. It features an unprecedented 120 dB signal-to-noise (SNR) ratio for the stereo line out and a 113 dB SNR for the line in, providing pristine audio quality. Additionally, an impedance-sensing circuit automatically adjusts gain to ensure an optimal volume range for your headphones.

Outshine The Competition
ASUS Aura Sync offers synchronized lighting with other Aura Sync products, including motherboards, graphics cards, monitors and peripherals.

Addressable RGB Gen 2 Headers
Automatically optimize lighting effects for the number of LEDs present in compatible ARGB gear.

Specifications

• Chipset : AMD B850 Chipset

• Memory

  • 4 x DIMM slots, max. 256GB, DDR5

  • Supports up to 8000+MT/s(OC) with Ryzen™ 9000 & 8000 & 7000 Series
  • Processors, ECC and Non-ECC Un-buffered DIMM*

  • Dual channel memory architecture

  • Supports AMD Extended Profiles for Overclocking (EXPO™)

  • ASUS Enhanced Memory Profile (AEMP)

  • * Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/download-center/. Adjustments will be made based on the specifications of mass-produced memory products available on the market.

  • * Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.
• Graphics

  • 1 x DisplayPort**

  • 1 x HDMI™ port***

  • * Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications.

  • ** Supports max. 8K@30Hz as specified in DisplayPort 1.4.

  • *** Supports 4K@60Hz as specified in HDMI 2.1.
• Expansion Slots

  • AMD Ryzen™ 9000 & 7000 Series Desktop Processors*

  • 1 x PCIe 5.0 x16 slot (supports x16 mode)

  • AMD Ryzen™ 8000 Series Desktop Processors

  • 1 x PCIe 4.0 x16 slot (supports x8/x4 mode)**

  • AMD B850 Chipset

  • 1 x PCIe 4.0 x16 slot (supports x4 mode)***

  • 1 x PCIe 4.0 x1 slot

  • * Please check the PCIe bifurcation table on the support site (https://www.asus.com/support/FAQ/1037507/).

  • ** Specifications vary by CPU types.

  • *** The M.2_3 slot shares bandwidth with the PCIEX16(G4) slot. When the
  • PCIEX16(G4) slot is operating, the M.2_3 slot will be disabled.

  • - To ensure compatibility of the device installed, please refer to https://www.asus.com/support/download-center/ for the list of supported peripherals.
• Storage

  • Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports

  • AMD Ryzen™ 9000 & 7000 Series Desktop Processors

  • M.2_1 slot (Key M), type 2280 (supports PCIe 5.0 x4 mode)

  • M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)

  • AMD Ryzen™ 8000 Series Desktop Processors

  • M.2_1 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)

  • M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4/x2 mode)*

  • AMD B850 Chipset

  • M.2_3 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)**

  • 4 x SATA 6Gb/s ports

  • * Specifications vary by CPU types.

  • ** The M.2_3 slot shares bandwidth with the PCIEX16(G4) slot. When the
  • PCIEX16(G4) slot is operating, the M.2_3 slot will be disabled.

  • AMD RAIDXpert2 Technology

  • Ryzen™ 9000 Series Processors: RAID 0/1/5/10

  • Ryzen™ 8000 Series Processors: RAID 0/1

  • Ryzen™ 7000 Series Processors: RAID 0/1/10
• Ethernet

  • 1 x Realtek 2.5Gb Ethernet

  • TUF LANGuard
• Wireless & Bluetooth

  • Wi-Fi 7*

  • 2x2 Wi-Fi 7 (802.11be)

  • Supports 2.4/5/6GHz frequency band**

  • Supports Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate

  • Bluetooth® v5.4***

  • * Wi-Fi features may vary depending on the operating system.

  • For Windows 11, Wi-Fi 7 will require 24H2 or later version for full functions,
  • Windows 11 21H2/22H2/23H2 only supports Wi-Fi 6E.

  • For Windows 10, only Wi-Fi 6 is supported.

  • ** Wi-Fi 6GHz frequency band and bandwidth regulatory may vary between countries.

  • *** The Bluetooth® version may vary, please refer to the Wi-Fi module manufacturer's website for the latest specifications.
• USB

  • Rear USB (Total 10 ports)

  • 1 x USB 20Gbps port (1 x USB Type-C®)

  • 3 x USB 10Gbps ports (3 x Type-A)

  • 4 x USB 5Gbps ports (4 x Type-A)

  • 2 x USB 2.0 ports (2 x Type-A)

  • Front USB (Total 7 ports)

  • 1 x USB 10Gbps connector (supports USB Type-C®)

  • 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports

  • 2 x USB 2.0 headers support 4 additional USB 2.0 ports

  • * USB Type-C® power delivery output: max. 5V/3A.
• Audio

  • Realtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC

  • - Impedance sense for front and rear headphone outputs

  • - Internal audio Amplifier to enhance the highest quality sound for headphone and speakers

  • - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking

  • - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)

  • - Supports up to 32-Bit/192 kHz playback*

  • Audio Features

  • - Audio Shielding

  • - Premium audio capacitors

  • - Dedicated audio PCB layers

  • - Audio cover

  • - Unique de-pop circuit

  • * Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1
  • Surround Sound audio.
• Back Panel I/O Ports

  • 1 x USB 20Gbps port (1 x USB Type-C®)

  • 3 x USB 10Gbps ports (3 x Type-A)

  • 4 x USB 5Gbps ports (4 x Type-A)

  • 2 x USB 2.0 ports (2 x Type-A)

  • 1 x DisplayPort

  • 1 x HDMI™ port

  • 1 x Wi-Fi module

  • 1 x Realtek 2.5Gb Ethernet port

  • 5 x Audio jacks

  • 1 x BIOS FlashBack™ button
• Internal I/O Connectors

  • Fan and Cooling Related

  • 1 x 4-pin CPU Fan header

  • 1 x 4-pin CPU OPT Fan header

  • 1 x 4-pin AIO Pump header

  • 4 x 4-pin Chassis Fan headers

  • Power Related

  • 1 x 24-pin Main Power connector

  • 2 x 8-pin +12V CPU Power connectors

  • Storage Related

  • 3 x M.2 slots (Key M)

  • 4 x SATA 6Gb/s ports

  • USB

  • 1 x USB 10Gbps connector (supports USB Type-C® )

  • 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports

  • 2 x USB 2.0 headers support 4 additional USB 2.0 ports

  • Miscellaneous

  • 3 x Addressable RGB Gen 2 headers

  • 1 x Clear CMOS header

  • 1 x Chassis Intrusion header

  • 1 x COM Port header

  • 1 x Front Panel Audio header (F_AUDIO)

  • 1 x 10-1 pin Front Panel System header

  • 1 x Thunderbolt™ (USB4®) header

  • BTF Related

  • 1 x 12V-2X6 Auxiliary Power connector

  • 1 x Graphics Card High-Power slot
• Special Features

  • ASUS TUF PROTECTION

  • - DIGI+ VRM (- Digital power design with DrMOS)

  • - ESD Guards

  • - TUF LANGuard

  • - Overvoltage protection

  • - SafeSlot

  • - Stainless-steel back I/O

  • ASUS Q-Design

  • - M.2 Q-Latch

  • - M.2 Q-Release

  • - PCIe Slot Q-Release Slim (with PCIe SafeSlot)

  • - Q-Antenna

  • - Q-Dashboard

  • - Q-DIMM

  • - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])

  • - Q-Slot

  • ASUS Thermal Solution

  • - M.2 heatsink

  • - VRM heatsink design

  • ASUS EZ DIY

  • - BIOS FlashBack™ button

  • - BIOS FlashBack™ LED

  • - ProCool

  • - Pre-mounted I/O shield

  • - SafeDIMM

  • Aura Sync

  • - Addressable RGB Gen 2 headers
• Software Features

  • ASUS Exclusive Software

  • Armoury Crate

  • - Aura Creator

  • - Aura Sync

  • - Fan Xpert 4

  • ASUS AI Advisor

  • ASUS DriverHub

  • ASUS GlideX

  • TurboV Core

  • TUF GAMING CPU-Z

  • DTS Audio Processing

  • Adobe Creative Cloud (Free Trial)

  • Norton 360 for Gamers (60 Days Free Trial)

  • WinRAR (40 Days Free Trial)

  • UEFI BIOS

  • ASUS EZ DIY

  • - ASUS CrashFree BIOS 3

  • - ASUS EZ Flash 3

  • - ASUS UEFI BIOS EZ Mode

  • - ASUS MyHotkey
• BIOS : 256 Mb Flash ROM, UEFI AMI BIOS
• Manageability : WOL by PME, PXE
• Accessories

  • Cables

  • 2 x SATA 6Gb/s cables

  • Miscellaneous

  • 1 x ASUS WiFi Q-Antenna

  • 1 x TUF Gaming sticker

  • 2 x M.2 rubber packages

  • Documentation

  • 1 x Quick start guide
• Operating System : Windows 11
• Form Factor

  • ATX Form Factor

  • 12 inch x 9.6 inch (30.5 cm x 24.4 cm)
