GIGABYTE X870 A ELITE X3D DDR5 Motherboard - Black

Key Features:

• X3D Turbo Mode 2.0 : Incredible X3D performance unleashed by AI

• DDR5 OC up to 8800MT/s

• DriverBIOS : Wi-Fi Driver Pre-install, Power-On & EZ to Launch the Network.

• AMD Socket AM5 : Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Processors

• Digital twin 16+2+2 phases VRM solution

• Dual Channel DDR5 : 4*DIMMs with AMD EXPO™Memory Module Support

• M.2 EZ-Flex : high-efficiency heat dissipation & flexible patented baseplate for M.2 SSD

• WIFI EZ-Plug : Quick and easy design for Wi-Fi antenna installation

• M.2 EZ-Latch Click & Plus : Quick Release & Screwless Design on M.2 slots and heatsinks

• Friendly UI : Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW

• Ultra-Fast Storage : 4*M.2 slots, including PCIe 5.0 x4

• Efficient Thermal : VRM Thermal Armor Advanced & M.2 Thermal Guard L & M.2 Thermal Guard Ext.

• Fast Networking : 5GbE LAN & Wi-Fi 7 with directional Ultra-high gain antenna

• Extended Connectivity : HDMI, Dual USB4 Type-C with DP-Alt

• PCIe UD Slot X : PCIe 5.0 x16 slot with 10X strength for graphics card

X3D Turbo Mode 2.0

X3D Turbo Mode 2.0 delivers enhanced gaming and multitasking performance over the first generation. Built-in AI model and hardware circuits dynamically optimize X3D processor parameters in real-time, significantly boosting Ryzen™ X3D performance. Through GIGABYTE's innovative X3D Turbo Mode 2.0 technology, users can enjoy a smoother gaming experience.

AORUS AI SNATCH
AORUS AI SNATCH Bullet Point
Unleash Ultimate Performance with One-Click Activation.Auto DDR5 Memory Boost
With just a single click, unleash the full potential of DDR5 memory, instantly boosting your gaming and work efficiency.

One-Click Acceleration:
Enhance DDR5 speeds with a single click.

Real time Analyze
OC accuracy UP
EZ to Pro

DDR5 Zenith-Memory
Zenith of the Memory
AORUS gaming motherboards boost DDR5 memory performance and offer top-notch compatibility using various advanced methods.

Top-tier Compatibility
DDR5 Overclocking Up to 8200 MT/s

Exclusive BIOS Design
Advanced BIOS functionality provides seamless optimization of industry-leading DDR5 memory performance.

AMD EXPO™ Settings
Optimize memory with AMD's user-friendly profiles.

AMD EXPO™ User Profile
Boost Performance: Get the most out of your system's memory.

Unmatched Hardware Excellence
Elevate your gaming with our state-of-the-art technology for a superior experience.

Sturdy VRM Design
Steady Power
Better Play AORUS Series, steady power keeps your gaming smooth.

Digital Twin VRM Design
Delivers consistent, high-powered performance to elevate your overclocking to the next level.

VCORE Phases DrMOS 60A
Unlock the full power of your multi-core CPU for unmatched performance.

SOC Phases DrMOS 60A
Optimized for integrated GPU performance and memory management within the CPU.

Cooling
Comprehensive Thermal
AORUS motherboards come with advanced full-metal thermal design and durable heatsinks to keep your system cool and efficient.

Easy & Friendly
Hassle-free Assembly
Our cutting-edge motherboard is designed for the ultimate DIY experience. Creating your own PC becomes a delightful and smooth process.

WIFI EZ-Plug
The WIFI EZ-Plug design integrates Wi-Fi antenna plugs into one adapter, EZ to install.

EZ-Latch Designs
User-friendly designs simplifying the assembly process.

PCB Mastery
Enhanced PCB Design for Superior Gameplay
Serving as the cornerstone of the motherboard, the PCB holds a fundamental and vital influence on system performance.

6L Server-grade PCB
Facilitates condensed integration, ensuring signal fidelity, power consistency, and diminished EMI for premium performance systems.

2X Copper Enhancement
Optimizes system efficiency through enhanced thermal management, improved power delivery, and comprehensive overclocking capabilities.

56% Lower Dissipation Factor
Our cutting-edge technology enhances signal integrity in high-frequency circuits, establishing new level in high-speed electronic engineering.

MISC Phases Ppak
Deliver reliable power to your CPU-connected PCIe lanes for uninterrupted performance.

All-round Connectivity
Experience ultimate connectivity with next-generation network, storage, and Wi-Fi solutions, delivering lightning-fast data transfer speeds.

Tailored Computing
Collaborative Excellence in Computing
GIGABYTE motherboards showcases our devotion to BIOS improvement. Through synergy with our user community, we democratize next-level computing power.

UC BIOS
Restructured with user-centered and intuitive performance adjustment mechanisms.

Multi-Theme
Multiple BIOS skin with newly exclusive grayscale mode

AIO Fan Control
Adjust AIO fan speed in the BIOS

Specifications

CPU

• AMD Socket AM5, support for:

• AMD Ryzen™ 9000 Series Processors/

• AMD Ryzen™ 8000 Series Processors/

• AMD Ryzen™ 7000 Series Processors

• (Go to GIGABYTE's website for the latest CPU support list.)

Chipset

• AMD X870

Memory

• Support for DDR5 8800(O.C) / 8600(O.C) / 8400(O.C) / 8200(O.C.)/ 8000(O.C) / 7800(O.C) / 7600(O.C) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400(O.C) / 6200(O.C) / 6000(O.C) / 5600(O.C) / 5200 / 4800 MT/s memory modules.

• 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory

• Dual channel memory architecture

• Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

• Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules

• (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" on GIGABYTE's website for more information.)

Onboard Graphics

• Integrated Graphics Processor with AMD Radeon™ Graphics support+ASMedia USB4® Controller:

• - 2 x USB4® USB Type-C® ports, supporting USB4 and DisplayPort video outputs and a maximum resolution of 3840x2160@240 Hz

• * Support for DisplayPort 1.4 version and HDR.

• Integrated Graphics Processor with AMD Radeon™ Graphics support:

• - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz

• * Support for HDMI 2.1 version, HDCP 2.3, and HDR.

• ** Support native HDMI 2.1 TMDS compatible ports.

• - 1 x front HDMI port, supporting a maximum resolution of 1920x1080@30 Hz

• * Support for HDMI 1.4 version

• (Graphics specifications may vary depending on CPU support.)


Audio

• Realtek® ALC1220 CODEC

• * The back panel line out jack supports DSD audio.

• High Definition Audio

• 2/4/5.1/7.1-channel

• * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.

• Support for S/PDIF Out

LAN

• Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)

Wireless Communication module

• Qualcomm® Wi-Fi 7 QCNCM865

• - 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands

• - BLUETOOTH 5.4

• - Support for 11be 320MHz wireless standard

  (Actual data rate may vary depending on environment and equipment.)

• * Wi-Fi 7 features require Windows 11 SV3 to function properly. (There is no support driver for Windows 10.)

• ** Wi-Fi 7 channels on 6 GHz band availability depends on individual country's regulations.

• ***Bluetooth version may change with updates. See the Wi-Fi chip vendor's website for details.

Expansion Slots

• 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:

• AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x16 mode

• AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode

• AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode

• (The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.)

• Chipset:

• - 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4)

• * The PCIEX4 slot shares bandwidth with the M2D_SB connector. The PCIEX4 slot becomes unavailable when a device is installed in the M2D_SB connector.


Storage Interface

• 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs:

• AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs

• AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs

• AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs

• 1 x M.2 connector (M2B_CPU), integrated in the CPU, supporting Socket 3, M key, type 22110/2280 SSDs:

• AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs

• The M2B_CPU connector shares bandwidth with the ASMedia USB4® controller.
  When a device is installed in the M2B_CPU connector, both the M2B_CPU connector and the USB4 port supported by the ASMedia USB4® controller operate at up to x2 bandwidth. When using an AMD Ryzen™ 8000 Series-Phoenix 1 or Phoenix 2 processor, the USB4 port supported by the ASMedia USB4® controller operates at up to x2 bandwidth, and the M2B_CPU connector becomes unavailable.

• 2 x M.2 connectors (M2C_SB, M2D_SB), integrated in the Chipset, supporting Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSDs

• 2 x SATA 6Gb/s connectors

• RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices
  * RAID 5 is only available on AMD Ryzen™ 9000 Series Processors.

• RAID 0 and RAID 1 support for SATA storage devices

USB

• CPU+ASMedia USB4® controller:

  - 2 x USB4® USB Type-C® ports on the back panel

• CPU:

  - 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support

  - 1 x USB 2.0/1.1 port on the back pane

• Chipset:

  - 1 x USB Type-C® port with USB 3.2 Gen 2x2 support, available through the internal USB header

  - 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel

  - 4 x USB 2.0/1.1 ports on the back panel

• Chipset+2 USB 3.2 Gen 1 Hubs:

  - 8 x USB 3.2 Gen 1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)

Internal I/O Connectors

• 1 x 24-pin ATX main power connector

• 2 x 8-pin ATX 12V power connectors

• 1 x CPU fan header

• 1 x CPU fan/water cooling pump header

• 4 x system fan headers

• 2 x system fan/water cooling pump headers

• 3 x addressable RGB Gen2 LED strip headers

• 1 x RGB LED strip header

• 4 x M.2 Socket 3 connectors

• 2 x SATA 6Gb/s connectors

• 1 x front panel header

• 1 x front panel audio header

• 1 x USB Type-C® header, with USB 3.2 Gen 2x2 support

• 2 x USB 3.2 Gen 1 header

• 2 x USB 2.0/1.1 headers

• 1 x noise detection header

• 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)

• 1 x HDMI port (Note)

• 1 x power button

• 1 x reset button

• 2 x temperature sensor headers

• 1 x reset jumper

• 1 x Clear CMOS jumper

Back Panel Connectors

• 1 x HDMI port (Note)

• 1 x power button

• 1 x reset button

• 1 x Q-Flash Plus button

• 1 x Clear CMOS button

• 2 x USB4® USB Type-C® ports (DisplayPort (Note))

• 1 x USB Type-C® port, with USB 3.2 Gen 2 support

• 2 x USB 3.2 Gen 2 Type-A ports (red)

• 4 x USB 3.2 Gen 1 ports

• 1 x USB 2.0/1.1 port

• 1 x RJ-45 port

• 2 x antenna connectors (2T2R)

• 1 x optical S/PDIF Out connector

• 2 x audio jacks

I/O Controller

• iTE® I/O Controller Chip

H/W Monitoring

• Voltage detection

• Temperature detection

• Fan speed detection

• Water cooling flow rate detection

• Fan fail warning

• Fan speed control

• * Whether the fan (pump) speed control function is supported will depend on the fan(pump) you install.

• Noise detection

BIOS

• 1 x 256 Mbit flash

• Use of licensed AMI UEFI BIOS

• PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Unique Features

• Support for GIGABYTE Control Center (GCC)

• * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.

• Support for Q-Flash

• Support for Q-Flash Plus

• Support Smart Backup

Bundled Software

• Norton® Internet Security (OEM version)


Operating System

• Support for Windows 11 64-bit

Form Factor

• ATX Form Factor; 30.5cm x 24.4cm
